Press Brake Die Types: Single-V, Multi-V & Adjustable
Press brake die types differ in how many V-openings they provide, how the opening is changed and which material range they serve. A single-V die gives one dedicated opening. A 2V or 4V multi-V die places several fixed openings on one rotatable body. An adjustable-V die moves and locks its side blocks to create different openings, often for thick-plate work.
Quick answer
Choose a single-V die when one opening matches a repeated job and you want the simplest setup. Choose a 2V or 4V multi-V die when several compatible fixed openings can reduce the number of separate dies in your tooling library. Consider an adjustable-V die when thick material, changing plate sizes and heavy die-handling requirements make fast opening changes valuable.
The die type never replaces the engineering checks. Select the opening from material thickness, target inside radius, minimum flange and force; then confirm die angle, shoulder radius, length, capacity, mounting style, installed height and safe handling for the exact tool.
Press brake die types compared
| Die type | How the V-opening is selected | Best starting use | Main trade-off |
|---|---|---|---|
| Single-V die | One fixed opening in one die | Repeat work, staged setups and applications needing a specific opening or profile | Another opening normally requires a different die or insert |
| 2V die | Rotate or reposition the die to expose one of two openings | Related sheet-metal ranges where two common V sizes cover regular work | The complete die must be safely handled, centred and locked after rotation |
| 4V or multi-V die | Rotate the block to one of up to four fixed openings | General-purpose flexibility with multiple V sizes in a compact library | Bulk, weight, centreline and unequal profile heights can limit staging and automation |
| Adjustable-V die | Move and lock side blocks or rollers at a selected spacing | Variable thick-plate work and applications where changing large fixed dies is inefficient | Higher cost, application-specific capacity and a more involved adjustment/locking procedure |
What the V-die does during air bending
In air bending, the punch contacts the sheet above the opening while the two die shoulders support it below. These three contact points let the sheet form through the opening without fully matching the die angle. Punch penetration primarily controls bend angle; the selected V-opening affects natural inside radius, minimum flange support and required force.
A different V-opening changes more than the space under the bend. A wider V generally produces a larger natural radius and requires less air-bending force for the same material and length, but it also needs a larger minimum flange. A narrower V supports a shorter flange and develops a smaller natural radius, but it raises the required force and can concentrate load.
Mate's general air-bending starting range uses approximately 6 times material thickness for 0.5 to 2.5 mm material, 8 times thickness for 2.5 to 8 mm, 10 times thickness for 8 to 10 mm and 12 times thickness above 10 mm. These are selection starting points, not permission to run the bend. Continue with the complete V-die opening guide and verify the exact chart.
Single-V press brake dies
One opening, one clearly defined setup
A single-V die has one working opening. That sounds less flexible than a multi-V block, but it is often the cleanest option for repeat production. The die can be selected with the exact opening, angle, shoulder radius, height, mounting interface and load rating needed for the job.
Single-V dies are also easier to organize in common-height systems. When compatible punches and dies share the required shut height, different stations can sometimes be staged across the press brake for several bends in one setup. AMADA and Wilson Tool both emphasize that staged tooling depends on common shut height; a die that looks similar but closes at another height cannot simply be placed beside the rest.
Choose single-V when:
- One V-opening covers a high-volume repeat job.
- You need a special angle, shoulder radius, surface treatment or non-standard profile.
- Common height and staged bending matter.
- The die must be sectionalized for boxes, returns or short bends.
- Tool-changing equipment makes separate dies easy to handle.
2V and 4V multi-V dies
A multi-V die combines multiple fixed openings in one body. A 2V die provides two openings; a 4V die normally provides an opening on each side. Mate describes multi-V dies with up to four V-openings, while its 2V options are designed to increase efficiency by carrying two openings on one die.
The attraction is tooling-library density: several openings travel together. That can reduce the number of separate blocks a shop stores. It does not eliminate setup work. The operator still has to support the die, rotate it safely, clean the contact surfaces, orient the correct face, centre the active opening and verify that the selected side's load rating and geometry match the program.
A multi-V die also should not be assumed to work like several independent common-height single-V dies. Changing faces can change overall geometry, centreline or effective height. A large block may not suit short segmented work, robotic changeover or a staged setup. Confirm these points from the drawing rather than from the number of openings.
Choose multi-V when:
- Two to four common openings cover a predictable material range.
- Storage space matters and the die can be rotated safely.
- The work is mostly straight bending rather than complex segmented stations.
- The machine, die holder and centring method accept the block.
- Operators have the lifting and handling method specified for the die.
Adjustable-V press brake dies
An adjustable-V die changes the opening by moving its side blocks or rollers, then locking them at an approved position. Wilson Tool positions adjustable dies for thick and heavy material where one adjustable assembly can replace several large fixed openings and reduce changeovers.
The two sides must be positioned symmetrically so the opening remains centred under the punch. The blocks then must be locked by the approved mechanism. Some systems are manual, some combine hydraulic clamping with manual movement, and others automate both clamping and positioning. The available range, increment, roller geometry and force capacity are specific to the design.
Adjustable dies can reduce the repeated lifting of heavy fixed dies, but they are not automatically best for thin sheet or highly segmented work. Consider the initial investment, maintenance, available bed space, part clearance, minimum opening, maximum opening, die-shoulder design and whether the shop's work mix uses the range often enough.
Choose adjustable-V when:
- The shop regularly bends several thicknesses of plate.
- Fixed dies for the required openings are large, heavy and slow to exchange.
- Fast opening changes can improve press-brake uptime.
- The parts are compatible with the die's support-block geometry and available range.
- The machine and tooling capacity cover every approved setting.
How to choose the correct press brake die
- Start from the drawing. Record material, measured thickness, bend length, final angle, inside radius, shortest flange, hole-to-bend distances, surface requirement and tolerances.
- Confirm the forming method. Air bending, bottoming, coining, hemming and large-radius forming need different die geometry and force. Do not use an air-bending rule for an unapproved bottoming setup.
- Select the V-opening. Use the material-thickness range as a starting point, then check the desired natural radius and minimum flange. A flange must remain supported on both die shoulders at the start of the bend.
- Calculate required force. Enter the actual material, thickness, bend length and V-opening in the press brake tonnage calculator, then compare the result with the manufacturer's chart.
- Check every capacity. Apply the lowest allowable load across the press brake, bed, ram, clamps, holders, punch, selected V face and any short sectional pieces. Do not assume every side of a multi-V die shares one rating.
- Choose the die architecture. Pick single-V for a dedicated, repeatable station; multi-V for several fixed openings in one block; adjustable-V for frequently changing heavy-plate openings.
- Verify angle and shoulder geometry. Confirm die angle, shoulder radius, surface condition and clearance for the selected punch. These affect overbend capability, marking and the path of the sheet.
- Confirm fit and installed height. Check mounting interface, base width, holder, centreline, overall height, shut height, daylight, stroke and safety-system compatibility.
- Plan handling and changeover. Record die weight, lifting points, rotation method, adjustment procedure, locking checks and storage. A flexible die is only productive when operators can handle it safely.
- Prove the setup. Run a controlled test bend with production-equivalent material. Measure the released angle, inside radius, flange and surface, then update the program and bend deduction from the result.
Other die details that change the result
| Detail | Why it matters | What to verify |
|---|---|---|
| Die angle | Determines available overbend and compatibility with the forming method | Punch angle, target released angle and springback allowance |
| Shoulder radius | Affects material travel, surface marking and die wear | Material finish, coating, burr direction and approved shoulder treatment |
| V-opening | Changes natural radius, minimum flange and air-bending force | Thickness ratio, part radius, flange support and tonnage chart |
| Tool height | Changes shut height, daylight and the ability to stage stations | Complete punch-plus-die installed geometry |
| Section length | Supports boxes and short bends but may reduce allowable concentrated load | Sectional load chart and minimum engaged length |
| Mounting style | Controls how the die locates, centres and locks to the brake | Machine bed, holder, tang/base geometry and approved adapters |
Single-V vs multi-V vs adjustable: buying decision
There is no universal best die type. The best purchase is the one that covers the shop's real thickness and part mix while remaining easy to identify, handle, set and verify. A lower-cost multi-V die can become inefficient if it is too heavy to rotate frequently. An adjustable die can be excellent for changing plate work but excessive for one thin-sheet production cell. A dedicated single-V die can look less flexible but deliver the most repeatable setup on a stable job.
Before ordering, group the previous six to twelve months of brake work by material, thickness, V-opening, bend length and frequency. That simple usage list reveals whether the shop needs one high-use single-V station, a compact set of multi-V openings or an adjustable plate-bending system.
Real press brake dies to compare
These are genuine catalogue products and images. They illustrate the die categories; exact fit, V-opening, force, height, length and application must be confirmed before ordering.
3223 Single-V Die - 80°
A dedicated 1V profile with multiple catalogue section lengths. Confirm V-opening and tooling interface from the product drawing.
View Single-V Die
2017 Two-V Die - 60°
A 2V die with a listed V16 opening and two catalogue lengths for a compatible lower-tooling system.
View Two-V Die
2030 Four-V Die - 85°/88°
A 4V profile listed at 60 mm height and 80 T/m. Confirm the opening on each face before selection.
View Four-V Die
3191 Adjustable Die
An adjustable-die system offered in several catalogue lengths. Request the opening range, holder and capacity data for your application.
View Adjustable DieInformation to send for a die recommendation
- Press brake make, model, year and lower-tooling interface
- Current die or holder profile drawing and clear square-on photographs
- Material grade, thickness range and maximum bend length
- Finished angle, inside radius and shortest flange
- Required V-openings and how often each opening is used
- Punch angle, nose radius, height and clamping style
- Available daylight, stroke, bed width and installed height
- Required sectional lengths and staged-bending plan
- Surface-finish and acceptable-marking requirements
- Production volume, changeover frequency and lifting equipment
Machinist's Vault supports fabrication shops in Canada and the United States. The request button opens the existing press-brake form so the application details can be reviewed before a die is recommended.
Press brake die types FAQ
What is the difference between a single-V and multi-V press brake die?
A single-V die has one fixed working opening. A multi-V die combines two or more fixed openings on one body and is rotated or repositioned to expose the required face. Multi-V saves storage space, while single-V can be simpler for dedicated and staged setups.
What is an adjustable-V press brake die?
An adjustable-V die changes its opening by moving and locking side blocks or rollers. It is commonly considered for changing thick-plate work where exchanging several large fixed dies would be slow or physically demanding.
Does a wider V-die opening reduce press brake tonnage?
For the same material, thickness and bend length in air bending, a wider V-opening generally reduces the required force. It also produces a larger natural inside radius and requires a larger minimum flange, so width cannot be increased without checking the part.
Can every side of a 4V die use the same tonnage?
Do not assume so. Opening size, profile section and manufacturer design can change the rating. Use the published load for the selected face, length and setup, and compare it with every other component in the system.
Can different press brake dies be staged together?
Only when their installed geometry and common shut height are designed for staging and the machine supports the setup. Otherwise one station can contact before another. Confirm punch and die heights, holder geometry and load distribution.
How do I choose the correct V-opening?
Start from material thickness, then verify finished inside radius, shortest flange, material strength and required force. Use the tooling manufacturer's air-bending chart and a test bend; generic thickness ratios are planning aids only.
Technical references
- Mate European Precision Style tooling - 1V, 2V, multi-V and die-insert descriptions and available ranges.
- Mate Press Brake FAQ - V-opening selection, minimum flange, radius and force considerations.
- Wilson Tool adjustable V-die guidance - adjustable opening concepts, thick-material use and changeover considerations.
- AMADA America: Excellence in Sheet Metal Starts at the Press Brake - V-opening, natural radius, force and common-height staging relationships.
