1317 - Punch 86°
1317 - Punch 86°
1317 - Punch 86°

1317 - Punch 86°

Length
Height
Angle

The 1317 Punch 86° is a sash punch designed for press brake tooling, primarily for Trumpf style press brakes. Crafted from 42CR steel, this punch offers a height of 195 mm, an angle of 86°, and a radius of 1 mm. It supports a maximum tonnage of 100 T/m and is available in multiple lengths including fractional sizes: 25, 30, 35, 40, 45, 50, 100, 200, 300, 500, 550 mm. For further inquiries about this product, its compatibility, or to request related videos or DXF files, please contact us. Product details are based on Eurostamp Tooling’s specifications for press brake tooling.

Overall Product Specifications

Material: High-grade hardened tool steel (42–48 HRC) for durability and wear resistance

Precision: CNC ground surfaces with ±0.01 mm tolerance for repeatable accuracy

Heights: Standard tooling heights (100–120 mm) with options for custom sizes

Form: Available in full-length or segmented pieces for easy setup and changeover

Shipping

Orders for press brake tooling ship within 1–2 weeks, depending on stock availability. In-stock items are dispatched quickly our warehouses, while custom or backordered items may take longer with lead times confirmed after purchase.

The Gold Standard in Press Brake Tooling

Eurostamp Tooling, a leading Italian manufacturer of high-quality press brake tooling, has partnered with Machinist’s Vault to offer precision punches, dies, and adapters across North America. This collaboration ensures fast local access to professional Press Brake tooling with expert support and reliable fulfillment.
Poster

Press Brake Tooling That Delivers

High-quality press brake tooling is essential for precision bending and long-term performance. Crafted from premium steel, induction hardened to 55–60 HRC, and finished with fine grinding, these punches, dies, and adapters are built for durability and accuracy. Now available through Machinist’s Vault, a full range of European-style press brake tooling is ready to ship across North America. Whether you need standard or custom solutions, you’ll get expert-backed support, fast fulfillment, and tooling you can trust for every bend.
