Wavlon Surge 35 — Tabletop CO2 Laser Cutter (35"×24")
Final price, electrical configuration, documentation, freight, and lead time are confirmed on the formal quote. Financing options available on request — ask your sales contact.
Faster. Safer. Stronger.
Production capability built around your workflow — cooling, control, and airflow, unified.
Built for uptime and flexible loading
Purpose-built details protect motion and optics, simplify daily production, and accommodate a wider range of workpieces.
Dust-covered optics
Lens and mirror covers reduce contamination and the need for frequent cleaning.
Fault alarm light
A visible tower light alerts operators when the machine reports a fault.
Up and down table
Powered vertical adjustment supports deeper workpieces with 10 or 30 cm configurations.
Independent power supply
Dedicated internal power architecture keeps critical systems organized and serviceable.
Hidden XY-axis guide rails
Enclosed guide-rail transmission supports smooth motion while reducing smoke and dust exposure to the belts and rails.
Pass-through door
Load longer or larger materials through the enclosure when the job requires additional reach.
Corrosion- and wear-resistant gears
Durable gear components are selected to resist corrosion and wear, supporting stable motion and longer service life.
Wavlon Surge 35 specifications
Standard values shown. Confirm the ordered electrical, table, and tube configuration before production.
| Working area | 600 × 900 mm |
| Table | Blade table; honeycomb optional |
| Transmission | Belt transmission for X and Y axes |
| Laser tube | Sealed CO2 glass tube, 60–80W CO2 |
| Laser tube cooling | Pure circulating water; Industrial CW-5200 |
| Positioning accuracy | 0.01 mm |
| Engraving speed | 0–1,100 mm/s |
| Cutting speed | 0–600 mm/s |
| Control / transmission | Ruida 8445; network / USB / U disk; USB offline |
| Included software | RDWorks V8 |
| Supporting software | LightBurn, Photoshop, AutoCAD, CorelDRAW |
| Power rating | 220V / 50Hz; 110V / 60Hz optional |
| Resume after power failure | Yes |
| Up and down table | 10/30 cm configuration with autofocus |
Cutting performance by peak power
Reference values from the supplier cutting chart. Material composition, optics, airflow, and settings affect results.
| Power / Peak Power | Acrylic | Wood | MDF |
|---|---|---|---|
| 80–100 W (this platform) | 10 mm | 10 mm | 5 mm |
| 100–130 W | 15 mm | 13 mm | 7 mm |
| 130–150 W | 20 mm | 18 mm | 10 mm |
| 150–180 W | 22 mm | 20 mm | 12 mm |
Standard equipment
Core motion, cooling, air, extraction, controls, and setup tools are organized into one practical package.
The blade table is standard. The honeycomb table and final vertical-travel option are confirmed at purchase.
Included software. Familiar tools.
Prepare jobs with the included controller software or connect a compatible third-party design workflow.
RDWorks V8
Controller software for Ruida job setup, file transfer, and USB-offline operation.
LightBurn
LightBurn Pro supports Ruida DSP controllers. A separate LightBurn licence may be required.
Compare the Wavlon CO2 lineup
Pick the working area and power class that fits your production volume.
| Wavlon Surge 28 | Wavlon Surge 35 | Wavlon Tide 51 | |
|---|---|---|---|
| Working Area | 500 × 700 mm | 600 × 900 mm | 900 × 1,300 mm |
| Laser Source | 50–80W CO2 | 60–80W CO2 | 130–180W CO2 |
| Max Engraving Speed | 800 mm/s | 1,100 mm/s | 1,100 mm/s |
| Max Cutting Speed | 500 mm/s | 600 mm/s | 800 mm/s |
| Control | Ruida | Ruida 8445 | Ruida 8445 |
| Table | Milled iron bed | Blade / honeycomb | Blade / honeycomb |
| Starting Price | Request Quote | $8,269 CAD | $9,189 CAD |
Cut. Engrave. Personalize.
A flexible CO2 workflow for production, prototyping, and custom work.
Wavlon CO2 machines are supplied with available FDA/CE documentation; CSA approval is available with purchase and does not currently carry blanket CSA/UL certification. Certification documents, warranty terms, and destination-market requirements are confirmed with the final quotation and order.
Backed for everyday production
Access technical help, warranty coverage, and a growing online source for consumables and replacement parts.
Remote service
Online service is available for setup, troubleshooting, and workflow questions.
In-person service
In-person service is available for installation, training, and technical support.
Machine warranty
The machine is covered by a one-year warranty, subject to the final sales terms.
Configure your Wavlon Surge 35
Tell us what you cut, engrave, or mark. We'll prepare the right configuration and delivery quote.
